RGS Manual Tool Changer 4UR
RGS manual tool changer is based on a simple yet effective design. This design allows an operator to easily change tools, preventing the wrong connection of a tool, and guaranteeing the highest precision. Optional electrical and compressed-air connectors are also available, allowing these functions to be changed quickly and safely. Both parts of the tool changer are a copy of the UR hole-pattern, making it even easier to retrofit the tool changer to existing gripper set-ups (programming has to be adapted to the additional height). Maximum payload: 15 kgs / 33 lbs.
- Available for any UR5 and UR10
- Simple Design
- Low Cost
- High Accuracy and Repeatability
- 15 kgs / 33 lbs payload = extra safety
How does it work?Simply align the two parts of the RGS Manual Tool-Changer and twist the locking collar of the upper part. You can feel that the tool is locked, and its design prevents any alignment issues as well as directional mistakes by the operator.
CB3.1, CB3.0, CB2
Diameter: 80 mm
Height: 52.5 mm
Weight: 450 grams
What's in the box:
Tool Changer Kit, Bolts, Installation Instructions, CE Certificate, Optional: Electrical Guide or Hose Guide .
